SPECIFICATIONS
- Up to 3.0 ATA (29 psi) operating pressure capabilities
- Mirrored interior/external controls for physician use and patient self-treatment
- Variable treatment pressures
- Tamper-proof redundant pressure regulators
- Adaptable ports for eternal medical pass-through devices
- Reinforced steel construction with handsome powder coated baby blue finish
- Manufactured with nontoxic, medical grade components
- Custom fit contoured mattress
- Portable and simple to move
- Split sections can easioly go through standard 36" doorway.
Steel Windows
Thickness .25 in (.63 cm) 1.25 in (3.17 cm)
Grade 70 Poly Carbon
Type 516 - Hybrid Alloy
Tensil Strength 70,000 lbs (31,751 kgs)
WEIGHT
Hard Shell Chamber: 1100 lbs (499 kgs)
Compressor: 37 lbs (16.78 kgs)
DIMENSIONS
Length: When bolted together it is 64 in in length (2 – 32in sections) with additional 32 inch
center sections available upon order
Shell Diameter: 42 inch
Door Diameter: 28 inch
CLEAN AIR COMPRESSOR
Double-headed, oil-less, 1/3 hp compressor with dual intake filters with cooling radiator
High-efficiency inline air filtration that filters air to 0.01 microns
Ask about our financing options for business!
Portable chambers are easy to operate and FDA approved for at home or clinic use. Take advantage of the convenience and cost savings of owning your own chamber!
